Used MCM CLOCK 1000 EVO | 5-Axes Horizontal Machining Center
Have one to sell?
ConditionUsed
CLOCK 1000 EVO: the mid-size machining center of the CLOCK EVO line
CLOCK 1000 EVO is the mid-size horizontal machining center of the CLOCK EVO line, characterized by a volume of 1.000 mm and by the pallet dimensions: 630 x 630 mm, 630 x 800 mm, or Ø 800 mm.
metric | imperial
CLOCK 1000 EVO
Axes Configuration - 5-Axes
Process Technology - Milling
Working Area
X-Axis Stroke - mm | in. - 1.000 | 39.4
Y-Axis Stroke - mm | in. - 1.000 | 39.4
Z-Axis Stroke - mm | in. - 1.100 | 43.3
X/Y/Z Axis Rapid Feed - m/min | ipm - 75 | 2,952.8
Pallet
Option 1 - mm | in. - 630 x 630 | 24.8 x 24.8
Option 2 (2) - mm | in. - 630 x 800 | 24.8 x 31.5
Rotary Table (B-Axis) - Max. Rotation Speed - min-1 - 100
5th Axis (A-Axis) Type – Tilting Table
Tilting Angle Degrees – 145 (+25/-120)
Spindle Unit Tool-Taper - HSK / ISO / CAPTO
Speed Range - min-1 - from 8.000 up to 30.000
Tool-Magazine - Capacity (up to)1 - No. - 80 (500+)
Available Configurations - Single-Pallet / Twin-Pallet / Multi-Pallet / FMS
