New UNISIGN UNIPORT7000-MTC | Multitasking Machining Centers
Have one to sell?
ConditionNew
New
Uniport7000-MTC
Mill-Turn capabilities
Powerful machining
Short lead times
When you need the flexibility of mill-turn operations on both single part and series production, choose the Uniport 7000-MTC. This multi-task CNC machine achieves extremely short lead times and very high accuracy, and is ideal for quick-response manufacturing. A high-rail gantry machine with a travelling bridge and stationary carousel turning station, it is built on our most flexible machine platform. It will perform 5-axis machining within a large working envelope, making it a truly cost-effective production choice for a wide range of applications. The innovative ‘box-in-box’ construction guarantees superb rigidity and very stable and accurate production processes.
Work Area
X-axis 3.000 - 6.500 mm
Y-axis 2.000 - 3.500 mm
Z-axis 1.600 mm
Distance spindle nose to table 500 - 2.100 mm
Table
Table size 2.000 - 6.000 ø mm
Swing circle 2.500 - 6.500 ø mm
Spindle
Gear box driven spindle and values 42/73 kW
6.000 min-1
1.600 Nm
Carousel turning station 95 kW
up to 135.000 Nm
Various
Tooling
Taper size HSK-A100 / Capto C8
Number of pockets # 52-206
Tool change time 10 sec
Speed
Rapid traverse 40.000 mm/min
Feed Rate 5 - 40.000 mm/min
Accessories
Right angular indexing head o
Universal indexing head o
Various turning tool adaptors o
5-axes machining o
In-process measuring o
